4306R-101-472LF by bourns
Image is representational - see mfr. specs

4306R-101-472LF

Bourns

Res Thick Film NET 4.7K Ohm 2% 0.75W(3/4W) ±100ppm/°C BUS Molded 6-Pin SIP Pin Thru-Hole ...

Datasheet
RoHS Compliant
TUBE Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 4306R-101-472LF is a thick-film molded SIP (Single In-line Package) resistor network from Bourns' 4300R Series, featuring a 6-pin bussed configuration with 4.7 kO resistance value and ±2% tolerance. This low-profile component incorporates five thick-film resistors of equal value, each connected between a separate pin and a common bus line, with a maximum operating voltage of 100 V and a temperature coefficient of resistance of ±100 ppm/°C. The device is rated for 0.30 watts per resistor at 70°C and features superior package integrity with RoHS-compliant tin-plated terminations. It is compatible with automatic insertion equipment and meets MIL-STD-202 environmental test requirements including short-time overload (±0.25%), load life (±1.00%), and moisture resistance (±0.50%). Common applications include DRAM termination, SCSI bus termination, and R/2R ladder networks in digital and analog circuits.

Search Keywords: 4306R101472LF

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
4306R-101-472LF
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536308000
COO:
CR
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
35
Package Type:
TUBE
Case Size:
N/R
Circuit Designator:
BUS
Number of Resistors:
5
Number of Terminals:
6
Power Rating:
0.75 (3/4) W
Power Rating per Resistor:
0.2 (1/5) W
Resistance Value:
4.7 KOhm
Tolerance:
2 %
Temperature Coefficient:
±100 ppm/°C
Termination Style:
Pin

IN STOCK: 1,715

Ships today, if you order in

Minimum Order Quantity: 35

Multiple: 35

Factory Lead-Time 7 Weeks

Price (USD)

Qty
Unit Price
35
$2.38
105
$1.94
280
$1.79
525
$1.78
1,015
$1.67
2,520
$1.63
5,005
$1.59
7,525 +
$1.58
Suppliers Standard Package
