4608X-102-222LF

Thick Film Conformal Coated Network Resistors ...

View Datasheet Ask the Datasheet
RoHS Compliant
OTHER Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 4608X-102-222LF is a thick-film conformal SIP resistor network featuring 8 isolated resistors of equal value (2,200 ohms each, as indicated by the 222 resistance code), each connected between two pins. This component operates at a maximum voltage of 100 V with a temperature coefficient of resistance of ±100 ppm/°C for the 50 O to 2.2 MO range, and maintains an insulation resistance of 10,000 MO minimum. The package delivers 1.00 W power rating at 70°C ambient temperature and operates reliably across the temperature range of -55°C to +125°C. The low-profile design is compatible with DIP packages, features RoHS-compliant Sn/Ag/Cu-plated terminations, and is recommended for rosin flux and solvent clean or no-clean flux processes. These resistor networks are commonly used in DRAM applications, SCSI termination, and other digital signal processing circuits requiring precision resistor arrays.

Search Keywords: 4608X102222LF

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
4608X-102-222LF
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8533100020
COO:
CN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1000
Package Type:
OTHER
Case Size:
N/R
Circuit Designator:
ISOL
Number of Resistors:
4
Number of Terminals:
8
Power Rating:
1 W
Power Rating per Resistor:
0.3 W
Resistance Value:
2.2 KOhm
Tolerance:
2 %
Temperature Coefficient:
±100 ppm/°C
Termination Style:
Pin

IN STOCK: 6,000

Ships today, if you order in

Minimum Order Quantity: 1000

Multiple: 1000

Factory Lead-Time 15 Weeks

Price (USD)

Qty
Unit Price
1,000
$0.1030
3,000
$0.1021
5,000
$0.0833
8,000
$0.0827
25,000
$0.0823
50,000
$0.0821
100,000
$0.0819
150,000 +
$0.0817
