5800-150-RC by bourns
Image is representational - see manufacturer specifications
Bourns Authorized Distributor

5800-150-RC

High Current RF Choke Bobbin Core 15uH 10% 1KHz Ferrite 1.9A 39mOhm DCR AXL ...

View Datasheet Ask the Datasheet
RoHS Compliant
TRAY Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 5800-150-RC is a high-current choke from Bourns' 5800 Series, designed for power supply filtering and electromagnetic interference (EMI) suppression in electronic circuits. It features an inductance of 15 µH (±10%) with a maximum DC resistance of 0.039 O, enabling efficient energy storage and minimal power loss. The component utilizes a ferrite bobbin core construction with VW-1 rated shrink tubing insulation, achieving a dielectric strength of 2500 Vrms and operating reliably across a temperature range of -40°C to +125°C. With a saturation current of 3.0 A and a rated current of 1.9 A, this choke is well-suited for moderate to high-current applications in switching power supplies, DC-DC converters, and noise filtering circuits where compact size and thermal stability are essential.

Search Keywords: 5800150RC

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
5800-150-RC
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8504508000
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
864
Package Type:
TRAY
Inductance:
15 uH
Type:
High Current RF Choke
Impedance:
N/A
Lead Pitch:
N/R
Tolerance:
10 %
Technology:
Bobbin Core
Maximum DC Resistance:
40 mOhm
Maximum DC Current:
1.28 A
Protection Style:
N/A
Packaging:
N/A

IN STOCK: 1,022

Ships today, if you order in

Minimum Order Quantity: 50

Factory Lead-Time 16 Weeks

Price (USD)

Qty
Unit Price
50
$1.558
250
$1.090
864
$0.996
1,728
$0.965
2,592
$0.962
5,184
$0.960
7,776
$0.937
10,368 +
$0.864
Supplier's Standard Package
