5800-183-RC by bourns
Image is representational - see mfr. specs

5800-183-RC

Bourns

High Current RF Choke Bobbin Core 18mH 10% 1KHz Ferrite 58mA 41Ohm DCR AXL ...

Datasheet
RoHS Compliant
TRAY Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 5800-183-RC is a high-current choke from Bourns' 5800 Series, designed for demanding power supply and filtering applications. It features an inductance of 18,000 µH (±10%) with a maximum DC resistance of 41.0 mO, enabling efficient energy storage and filtering with minimal power loss. The component is rated for a saturation current of 0.080 A and a continuous rated current of 0.058 A, with a ferrite bobbin core construction and VW-1 rated shrink tubing for insulation. Operating across a temperature range of -40°C to +125°C with a dielectric strength of 2500 Vrms, this choke is well-suited for high-inductance applications in switching power supplies, DC-DC converters, and EMI filtering circuits where space and efficiency are critical.

Search Keywords: 5800183RC

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
5800-183-RC
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8504508000
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
864
Package Type:
TRAY
Inductance:
18 mH
Type:
High Current RF Choke
Impedance:
N/A
Lead Pitch:
N/R
Tolerance:
10 %
Technology:
Bobbin Core
Maximum DC Resistance:
48.3 Ohm
Maximum DC Current:
39 mA
Protection Style:
N/A
Packaging:
N/A

IN STOCK: 919

Ships today, if you order in

Minimum Order Quantity: 50

Factory Lead-Time 16 Weeks

Price (USD)

Qty
Unit Price
50
$0.820
250
$0.675
864
$0.629
1,728
$0.613
2,592
$0.590
5,184
$0.588
7,776
$0.576
10,368 +
$0.574
Suppliers Standard Package
