6701-RC by bourns
Image is representational - see mfr. specs

6701-RC

Bourns

Inductor High Current Toroid 10uH/5uH 15% 1KHz 11A 8mOhm DCR Pin ...

Datasheet
RoHS Compliant
Packaging
Accessories
Discontinued
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 6701-RC is a high-current toroid inductor designed for applications requiring low radiation and high current capacity. It features an inductance of 10 µH (±15% @ 1 kHz) with a maximum current rating of 11.0 A and a minimum inductance of 5 µH at rated current. The inductor is mounted on a UL 94V-0 rated header with fixed pins for easy PCB insertion, and exhibits a maximum DC resistance of 0.008 O. Operating over a temperature range of -55°C to +105°C, this component is ideal for power supply circuits, filtering applications, and other high-current electronic systems where compact size and reliable performance are essential.

Search Keywords: 6701RC

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
6701-RC
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8504508000
COO:
TW
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
66
Inductance:
10(OCL)/5 uH
Type:
High current
Impedance:
N/A
Lead Pitch:
15.24 mm
Tolerance:
15 %
Technology:
Toroid
Maximum DC Resistance:
8 mOhm
Maximum DC Current:
11 A
Protection Style:
N/A
Packaging:
N/A
Life Cycle:
Discontinued
  This product is discontinued, but still in stock

IN STOCK: 148

Can Ship immediately

Price (USD)

Qty
Unit Price
1
$2.85
25
$2.79
50
$2.74
100
$2.68
500
$2.63
1,000 +
$2.58
