Image is representational - see manufacturer specifications
Bourns Authorized Distributor

81A2A-G36-A15/A15L

A dual-section, single-turn cermet panel control potentiometer with two 10 kOhm linear taper sections and PC pin terminals. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 81A2A-G36-A15/A15L is a dual-section, single-turn panel control potentiometer designed for manual adjustments. It features a cermet resistive element for both sections, each providing 10 kOhms of resistance with a linear taper and a ±10% tolerance. This model is constructed with a 3/8-inch plain bushing, a dual concentric plain shaft (1/4" and 1/8" diameters) measuring 1-1/8" in length, and PC pin terminals for board mounting. As a RoHS compliant component with a rotational life of 100,000 cycles, it is well-suited for industrial controls, test equipment, and other applications requiring two independent adjustments from a single, durable control.

Search Keywords: 81A2AG36A15A15L

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
81A2A-G36-A15/A15L
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8533408070
COO:
HU
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Mounting:
Panel Mount/Through Hole
Number of Turns:
1(Elec),1(Mech) Tur ns
Termination Style:
Pin
Power Rating:
1 W
Resistance Value:
10/10 KOhm
Tolerance:
10 %
Temperature Coefficient:
±150 ppm/°C
Dimension:
54.62 x 15.88 x 17.52 mm
Operating Temperature:
-40 to 125 °C
Switch Option:
No
Number of Elements:
2

IN STOCK: 0

On Order: 5   can ship 11/2/26

MOQ for In Stock Qty: 68

MOQ for out of Stock Qty: 68

Factory Lead-Time 9 Weeks

Price (USD)

Qty
Unit Price
1
$65.49
68
$59.53
135
$31.75
203
$22.29
270 +
$21.85
