95A1A-B28-A13L by bourns
Image is representational - see mfr. specs

95A1A-B28-A13L

Bourns

Res Cermet POT 5K Ohm 10% 2W 1(Elec)/1(Mech)Turn 6.35mm (34.93 X 15.88 X 22.55mm) Solder Lug Panel Mount ...

Datasheet
RoHS Compliant
TRAY Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 95A1A-B28-A13L is a Model 95 single-turn panel control potentiometer featuring triangle-pattern solder lugs and a 7/8" (28 mm) metal plain bushing with a 10 mm diameter and 9 mm length. This device uses a cermet resistive element with a linear taper (H code) and ±5% tolerance, supporting resistance values from 100 ohms to 1 megohm. The potentiometer is available with standard shaft lengths of 16.0 mm (0.630") or 22.0 mm (0.866"), with shaft type "V" dimensions of 1.50 ± 0.25 mm diameter. It features virtually infinite electrical circuit isolation and is RoHS compliant, making it suitable for audio equipment, industrial control panels, and consumer electronics requiring precise resistance adjustment with reliable solder lug termination.

Search Keywords: 95A1AB28A13L

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
95A1A-B28-A13L
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8533408050
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
45
Package Type:
TRAY
Mounting:
Panel Mount
Number of Turns:
1(Elec),1(Mech) Turns
Termination Style:
Solder
Power Rating:
2 W
Resistance Value:
5 KOhm
Tolerance:
10 %
Temperature Coefficient:
±150 ppm/°C
Dimension:
34.93 x 15.88 x 22.55 mm
Operating Temperature:
-40 to 125 °C
Switch Option:
No
Number of Elements:
1

IN STOCK: 72

Ships today, if you order in

Minimum Order Quantity: 45

Multiple: 45

Factory Lead-Time 7 Weeks

Price (USD)

Qty
Unit Price
45
$5.29
90
$5.10
135
$5.09
270
$4.93
540
$4.92
1,035
$4.87
2,520
$4.81
5,040 +
$4.80
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
