HCTSM80102AAL-E1 by bourns
Image is representational - see manufacturer specifications
Bourns Authorized Distributor

HCTSM80102AAL-E1

Pulse Transformers - Primary Inductance - 250µH - 350mA - Turns ratio 1:2 ...

View Datasheet Ask the Datasheet
RoHS Compliant
Reel Packaging
Accessories
Discontinued
Certificate of Compliance

DESCRIPTION

HCTSM80102AAL-E1 is an automotive-grade isolation transformer designed for high-voltage power supply applications, featuring a toroid core for high coupling and low radiation. The transformer provides reinforced insulation rated for 800 Vrms and 1000 Vpeak working voltage, with a primary inductance of 250 µH at 100 kHz and 1 V, and a turns ratio of 1:1. It exhibits low leakage inductance of 0.8 µH maximum and minimal DC resistance (0.30 O primary, 0.20 O secondary), ensuring efficient power transfer with minimal losses. The device is AEC-Q200 compliant, RoHS compliant, and UL 62368-1 recognized, making it suitable for isolation power supplies using TI SN6501, SN6505B, and Nexperia NXF6501-Q100 controllers in automotive and industrial applications requiring high clearance and creepage distance.

Search Keywords: HCTSM80102AALE1

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
HCTSM80102AAL-E1
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8504312000
COO:
CN
ECCN:
EAR99
Reel Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
500
Package Type:
Reel
Life Cycle:
Discontinued
  This product is discontinued, but still in stock
  Possible Replacement options available.  See Alternatives

IN STOCK: 451

Ships today, if you order in

Price (USD)

Qty
Unit Price
1
$2.76
25
$2.72
50
$2.66
250
$2.60
500
$2.55
1,000 +
$2.49
Reel Package
