PEC16-4020F-N0024 by bourns
Image is representational - see mfr. specs

PEC16-4020F-N0024

Bourns

The PEC16-4020F-N0024 is a 16 mm incremental encoder with a resolution of 24 pulses per revolution, a 20 mm insulated flatted shaft, and no switch. ...

Datasheet
RoHS Compliant
TRAY Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The PEC16-4020F-N0024 is a 16 mm incremental encoder designed for user interface controls. This model features a horizontal PC pin layout, no detents for smooth rotation, a 20.0 mm insulated flatted shaft, and does not include a push switch. It provides a 2-bit quadrature code output with a resolution of 24 pulses per 360° rotation and has a contact rating of 1 mA at 5 VDC. Designed for high reliability, the encoder has a rotational life of at least 100,000 cycles and operates in temperatures from -30 °C to +70 °C. It is well-suited for level control, tuning, and timer settings in audio equipment, radios, and consumer appliances.

Search Keywords: PEC164020FN0024

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
PEC16-4020F-N0024
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8543704500
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Package Type:
TRAY
Bearings:
N/A
Built-in Switch:
No
Body Orientation:
Straight

IN STOCK: 0

On Order: 1,200   can ship 5/18/26

Minimum Order Quantity: 50

Multiple: 50

Factory Lead-Time 16 Weeks

Price (USD)

Qty
Unit Price
50
$1.148
250
$0.933
500
$0.866
1,000
$0.863
2,500
$0.808
5,000
$0.786
7,500
$0.784
10,000 +
$0.766
Suppliers Standard Package
