PQ2614BLA-2R2K by bourns
Image is representational - see manufacturer specifications
Bourns Authorized Distributor

PQ2614BLA-2R2K

Ind,27.9x27.9x16mm,2.2uH10%,30A,Shd,SMD ...

View Datasheet Ask the Datasheet
RoHS Compliant
TRAY Packaging
Accessories
Certificate of Compliance

DESCRIPTION

PQ2614BLA-2R2K is a magnetically shielded power inductor from the PQ2614BLA/BHA series designed for high-current DC-DC converter and power supply applications. It features a flat wirewound construction with an inductance of 2.2 µH (±10%) at 100 kHz, a typical DC resistance of 1.29 mO, and a self-resonant frequency of 50 MHz. The inductor supports an RMS current rating of 30 A typical, with saturation current (Isat1) of 84.0 A and (Isat2) of 84.8 A, providing excellent current handling capability. It includes an extra solder pad for increased mechanical stability and is AEC-Q200 compliant, RoHS compliant, and halogen-free, making it suitable for automotive and industrial power management circuits requiring reliable, compact energy storage.

Search Keywords: PQ2614BLA2R2K

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
PQ2614BLA-2R2K
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8504508000
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
200
Package Type:
TRAY
Inductance:
2.2 uH
Type:
Power7105
Impedance:
N/A
Tolerance:
107104%
Technology:
Wirewound7103
Maximum DC Current:
30(Typ) A
Maximum DC Resistance:
0.0016 Ohm
Operating Temperature:
-40 to 155 °C
Packaging:
Tray
Protection Style:
Shielded7102

IN STOCK: 0

MOQ for out of Stock Qty: 150

Factory Lead-Time 15 Weeks

Price (USD)

Qty
Unit Price
150
$2.75
300
$2.07
450
$1.94
600 +
$1.90
Log in for special pricing Click for Quote Price Match Request
