RJ26FW201 by bourns
Image is representational - see manufacturer specifications
Bourns Authorized Distributor

RJ26FW201

Res Cermet Trimmer 200 Ohm 10% 0.25W(1/4W) 12(Elec)Turn 1.78mm (6.35 X 4.32 X 7.37mm) Pin Thru-Hole Tube ...

View Datasheet
RoHS Non-Compliant
TUBE Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The RJ26FW201 is a sealed multiturn cermet trimming potentiometer (Trimpot) designed for precision resistance adjustment in industrial and military applications. It features a standard resistance range from 10 ohms to 1 megohm with ±10% tolerance, infinite resolution, and exceptional adjustability of ±0.02% for voltage and ±0.05% for resistance. The device is rated for 0.25 watt at 85 °C (maximum 200 volts), operates across -65 °C to +150 °C with a temperature coefficient of ±100 PPM/°C, and provides 1000 megohms minimum insulation resistance with 600 VAC dielectric strength at sea level. It withstands 20 g vibration and 100 g shock with 12 turns of effective travel and is qualified to MIL-PRF-22097 and MIL-PRF-39035 standards. This sealed design is ideal for circuit calibration, gain adjustment, and offset trimming in aerospace, defense, and industrial instrumentation where reliability and precision are critical.

Search Keywords: RJ26FW201

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
RJ26FW201
Unit of Measure:
Per Each
RoHS:
No
HTS:
8533408050
COO:
CR
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
200
Package Type:
TUBE
Mounting:
Through Hole
Number of Turns:
12(Elec) Turns
Termination Style:
Pin
Power Rating:
0.25 (1/4) W
Resistance Value:
200 Ohm
Tolerance:
10 %
Temperature Coefficient:
±100 ppm/°C
Dimension:
6.35 x 4.32 x 7.37 mm
Operating Temperature:
-65 to 150 °C

IN STOCK: 66

Ships today, if you order in

Minimum Order Quantity: 5

Factory Lead-Time 9 Weeks

Price (USD)

Qty
Unit Price
5
$4.77
25
$4.41
200
$4.11
400
$3.98
600
$3.97
1,000
$3.92
2,600
$3.87
5,000 +
$3.86
Supplier's Standard Package
