RLB9012-470KL by bourns
Image is representational - see manufacturer specifications
Bourns Authorized Distributor

RLB9012-470KL

Inductor Power Wirewound 47uH 10% 1KHz 30Q-Factor Ferrite 1.77A 0.16Ohm DCR RDL Bag ...

View Datasheet Ask the Datasheet
RoHS Compliant
TRAY Packaging
Accessories
Certificate of Compliance

DESCRIPTION

RLB9012-470KL is a radial leaded inductor designed for power supply and DC/DC converter applications. It features an inductance of 47.0 µH ± 10% measured at 1 kHz, with a Q factor reference of 30 at a test frequency of 2.52 MHz. The inductor has a maximum DC resistance of 0.160 ohms and supports a maximum rated DC current of 1.77 A with only 5% inductance drop. Constructed with a ferrite DR core and enameled copper wire, it operates reliably over a temperature range of -55°C to +125°C. This RoHS compliant component is well-suited for general use in power electronics where compact radial packaging is required.

Search Keywords: RLB9012470KL

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
RLB9012-470KL
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8504508000
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
200
Package Type:
TRAY
Inductance:
47 uH
Type:
Power
Impedance:
N/A
Lead Pitch:
5 mm
Tolerance:
10 %
Technology:
Wirewound
Maximum DC Resistance:
160 mOhm
Maximum DC Current:
1.77 A
Protection Style:
N/A
Packaging:
Bag

IN STOCK: 2,802

Can Ship immediately

Minimum Order Quantity: 200

Multiple: 200

Factory Lead-Time 14 Weeks

Price (USD)

Qty
Unit Price
200
$0.3799
600
$0.3383
2,600
$0.3105
5,000
$0.3015
7,600
$0.2985
10,000
$0.2978
15,000
$0.2971
25,000 +
$0.2962
Supplier's Standard Package
Log in for special pricing Click for Quote Price Match Request
