SDR0403-220ML by bourns
Image is representational - see mfr. specs

SDR0403-220ML

Bourns

Inductor Power Wirewound 22uH 20% 1KHz 25Q-Factor Ferrite 760mA 380mOhm DCR T/R ...

Datasheet
RoHS Compliant
REEL Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

SDR0403-220ML is a surface-mount power inductor from Bourns' SDR0403 series designed for input/output filtering in DC/DC converters and power supplies. It features a 22 µH inductance at 1 kHz with ±20% tolerance, a low profile height of 3.2 mm maximum, and a ferrite DR core with enameled copper wire construction. The inductor has a maximum DC resistance of 0.38 O, rated RMS current of 0.76 A, and saturation current of 1.20 A, with a self-resonant frequency of 20 Hz minimum. It is RoHS compliant and suitable for portable communications equipment, camcorders, and LCD TV power supplies where compact form factor and reliable performance are essential.

Search Keywords: SDR0403220ML

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
SDR0403-220ML
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8504508000
COO:
CN
ECCN:
EAR99
Reel Pack: This product ships on a reel. Depending on the quantity ordered, you may receive full factory reels, cut tape (components on a strip cut from a reel), or a combination of both.
2000
Package Type:
REEL
Inductance:
22 uH
Type:
Power
Impedance:
N/A
Tolerance:
20 %
Technology:
Wirewound
Maximum DC Current:
760 mA
Maximum DC Resistance:
380 mOhm
Operating Temperature:
-40 to 125 °C
Packaging:
Tape and Reel
Protection Style:
N/A

IN STOCK: 2,000

Ships today, if you order in

Minimum Order Quantity: 2000

Multiple: 2000

Factory Lead-Time 14 Weeks

Price (USD)

Qty
Unit Price
2,000
$0.1886
4,000
$0.1859
6,000
$0.1833
8,000
$0.1809
10,000
$0.1805
26,000
$0.1775
50,000
$0.1754
100,000 +
$0.1749
Reel Package
Log in for special pricing Click for Quote Price Match Request
