SDR1806-102KL by bourns
Image is representational - see mfr. specs

SDR1806-102KL

Bourns

The SDR1806-102KL is a surface-mount power inductor featuring a 1000 µH inductance and a ±10% tolerance. ...

Datasheet
RoHS Compliant
REEL Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The SDR1806-102KL is a RoHS compliant, SMD power inductor from the SDR1806 series. It provides a nominal inductance of 1000 µH, a maximum DC resistance of 1800.0 mΩ, and a typical saturation current (Isat) of 1.00 A. This component features a maximum RMS current (Irms) of 0.50 A, a typical self-resonant frequency of 2.0 MHz, and a low profile of just 6.6 mm. It is designed for an operating temperature range of -40 °C to +125 °C, making it suitable for the input/output of DC/DC converters and power supplies in portable equipment, camcorders, and LCD TVs.

Search Keywords: SDR1806102KL

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
SDR1806-102KL
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8504508000
COO:
CN
ECCN:
EAR99
Reel Pack: This product ships on a reel. Depending on the quantity ordered, you may receive full factory reels, cut tape (components on a strip cut from a reel), or a combination of both.
250
Package Type:
REEL
Inductance:
1 mH
Type:
Power
Impedance:
N/A
Tolerance:
10 %
Technology:
Wirewound
Maximum DC Current:
500 mA
Maximum DC Resistance:
1.8 Ohm
Operating Temperature:
-40 to 125 °C
Packaging:
Tape and Reel
Protection Style:
N/A

IN STOCK: 2,000

Can Ship immediately

Minimum Order Quantity: 250

Multiple: 250

Factory Lead-Time 16 Weeks

Price (USD)

Qty
Unit Price
250
$0.5842
500
$0.5256
1,000
$0.4937
2,500
$0.4637
5,000
$0.4612
7,500
$0.4486
10,000
$0.4434
15,000 +
$0.4385
Reel Package
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

Product Guides

Product Changes
