SM453229A-381N7Y by bourns
Image is representational - see manufacturer specifications
Bourns Authorized Distributor

SM453229A-381N7Y

The SM453229A-381N7Y is an automotive-grade, 10/100/1000 Base-T chip LAN transformer compatible with IEEE 802.3 standards. ...

View Datasheet Ask the Datasheet
RoHS Compliant
REEL Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The SM453229A-381N7Y is a discrete chip LAN transformer designed for 10/100/1000 Base-T Ethernet applications. It provides a minimum inductance of 380 µH at 100 kHz (0.1V, 0mA) and exhibits a maximum insertion loss of -1.5 dB across the 1-100 MHz frequency range. The component features a 1:1 turns ratio and is built to withstand a Hi-Pot test of 1500 Vac and a pulse voltage of 2400 V. As an AEC-Q200 compliant device with an expanded operating temperature range of -40 °C to +105 °C, it is well-suited for demanding automotive environments. The discrete design allows for flexible PCB layout and can be paired with a common mode choke for enhanced EMI reduction.

Search Keywords: SM453229A381N7Y

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
SM453229A-381N7Y
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8504312000
COO:
TW
ECCN:
EAR99
Reel Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
2000
Package Type:
REEL

IN STOCK: 6,000

Ships today, if you order in

Minimum Order Quantity: 2000

Factory Lead-Time 14 Weeks

Price (USD)

Qty
Unit Price
2,000
$0.4190
4,000
$0.4180
6,000
$0.4169
8,000
$0.4159
10,000
$0.4148
16,000
$0.4094
26,000
$0.4051
50,000 +
$0.4041
Reel Package
Log in for special pricing Click for Quote Price Match Request
