SM-LP-5001E by bourns
Image is representational - see mfr. specs

SM-LP-5001E

Bourns

Audio Transformer - Turns Ratio 1:1 - 2000 Vrms - 115 Ohm Primary - 115 Ohm Secondary - 6 Terminals - Gull Wing. ...

Datasheet
RoHS Compliant
REEL Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The SM-LP-5001E is a line matching Audio Transformer, 1:1 turn ratio, 600R primary/secondary impedance with Sn/Ag/Cu terminal plating and surface mount. This transformer features subminiature in SMT, distortion of 0.015%, vacuum encapsulated. Suitable for modems (V32). Suitable applications for these line matching transformers include instrumentation, telecommunications, laptops and modems (V32). Operating temperature ranges from -20°C to +85°C.

Search Keywords: SMLP5001E

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
SM-LP-5001E
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8504312000
COO:
CN
ECCN:
EAR99
Reel Pack: This product ships on a reel. Depending on the quantity ordered, you may receive full factory reels, cut tape (components on a strip cut from a reel), or a combination of both.
400
Package Type:
REEL
Operating Frequency:
0.2 to 4 kHz
Frequency Response:
±0.25 dB
Package Type:
N/A
Turns Ratio:
1:1
Packaging:
Tape and Reel
Primary Side Voltage:
N/A
Secondary Side Impedance:
N/A
  Possible Replacement options available.  See Alternatives

IN STOCK: 15,600

Ships today, if you order in

Minimum Order Quantity: 400

Multiple: 400

Factory Lead-Time 16 Weeks

Price (USD)

Qty
Unit Price
400
$1.58
800 +
$1.57
Reel Package
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments
