SRN3015TA-150M by bourns
Image is representational - see manufacturer specifications
Bourns Authorized Distributor

SRN3015TA-150M

Inductor Power Semi-Shielded Wirewound 15uH 20% 100KHz 12Q-Factor Ferrite 700mA 320mOhm DCR 1212 Automotive T/R ...

View Datasheet Ask the Datasheet
RoHS Compliant
REEL Packaging
Accessories
Certificate of Compliance

DESCRIPTION

SRN3015TA-150M is a semi-shielded power inductor from Bourns designed for use in switching power supplies, DC-DC converters, and other power management circuits. The device features a 15 µH inductance with ±20% tolerance, a minimum Q factor of 12 at 100 kHz, and a self-resonant frequency of 23 MHz typical. It is rated for 0.7 A RMS current with a saturation current of 0.65 A, and exhibits a DC resistance of 0.32 O (±20%). The inductor operates reliably over a temperature range of -40°C to +125°C with a 40°C temperature rise at rated current, and is constructed with a ferrite core, enameled copper wire, and magnetic epoxy resin coating. This AEC-Q200 compliant, RoHS-compliant, and halogen-free component is ideal for automotive and industrial power applications requiring high reliability and compact form factors.

Search Keywords: SRN3015TA150M

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
SRN3015TA-150M
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8504508000
COO:
CN
ECCN:
EAR99
Reel Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
2000
Package Type:
REEL
Inductance:
15 uH
Type:
Power
Impedance:
N/A
Tolerance:
20 %
Technology:
Wirewound
Maximum DC Current:
0.7 A
Maximum DC Resistance:
0.32(Typ) Ohm
Operating Temperature:
-40 to 125 °C
Packaging:
Tape and Reel
Protection Style:
Semi-Shielded

IN STOCK: 492,000

Ships today, if you order in

Minimum Order Quantity: 2000

Multiple: 2000

Factory Lead-Time 12 Weeks

Price (USD)

Qty
Unit Price
2,000
$0.2911
4,000
$0.2819
6,000
$0.2812
8,000
$0.2805
10,000
$0.2748
26,000
$0.2678
50,000
$0.2672
100,000 +
$0.2467
Reel Package
