SRR6603-102ML by bourns
Image is representational - see mfr. specs

SRR6603-102ML

Bourns

Inductor Power Shielded Wirewound 1mH 20% 100KHz 40Q-Factor Ferrite 150mA 3.4Ohm DCR T/R ...

Datasheet
RoHS Compliant
REEL Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

SRR6603-102ML is a shielded power inductor from the SRR6603 series designed for input/output filtering in DC/DC converters and power supply applications. The device features a ferrite core with enameled copper wire and ceramic base, delivering 1000 µH inductance with ±20% tolerance and a maximum DC resistance of 3.4 O. It operates across a temperature range of -55°C to +125°C with a rated current (Irms) of 0.15 A and saturation current (Isat) of 0.045 A, achieving a self-resonant frequency of 2 MHz. The compact 3 mm unit height and RoHS-compliant construction make it ideal for portable communication equipment, camcorders, LCD TVs, and radio power supplies where space and reliability are critical.

Search Keywords: SRR6603102ML

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
SRR6603-102ML
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8504508000
COO:
CN
ECCN:
EAR99
Reel Pack: This product ships on a reel. Depending on the quantity ordered, you may receive full factory reels, cut tape (components on a strip cut from a reel), or a combination of both.
600
Package Type:
REEL
Inductance:
1 mH
Type:
Power
Impedance:
N/A
Tolerance:
20 %
Technology:
Wirewound
Maximum DC Current:
150 mA
Maximum DC Resistance:
3.4 Ohm
Operating Temperature:
-55 to 125 °C
Packaging:
Tape and Reel
Protection Style:
Shielded

IN STOCK: 1,800

Can Ship immediately

Minimum Order Quantity: 600

Multiple: 600

Factory Lead-Time 16 Weeks

Price (USD)

Qty
Unit Price
600
$0.5885
1,200
$0.5246
3,000
$0.5054
5,400
$0.5024
7,800
$0.4965
10,200
$0.4952
15,000
$0.4940
25,200 +
$0.4928
Reel Package
