SRU8043-2R2Y

Name: SRU8043-2R2Y
Brand: Bourns
SKU: 10761026
Price: 445 USD
Availability: BackOrder

General Purpose Inductor - 2.2uH - 30% - 1 Element - Ferrite-Core - SMD - 3131 ...

View Datasheet Ask the Datasheet

RoHS Compliant

REEL Packaging

Certificate of Compliance

DESCRIPTION

SRU8043-2R2Y is a shielded SMD power inductor designed for DC/DC converter input/output filtering and power supply applications. It features an inductance of 2.2 µH at 100 kHz with ±30% tolerance, a maximum RMS current rating of 5.4 A, and a saturation current of 5.20 A typical. The inductor has a low DC resistance of 11.2 mO, a self-resonant frequency minimum of 65.0 MHz, and operates reliably across a storage temperature range of -40°C to +125°C with a maximum temperature rise of 40°C at rated current. With a compact unit height of 4.3 mm and RoHS compliance, this component is ideal for portable communication equipment, camcorders, and LCD TV power supplies where space efficiency and thermal performance are critical.

Product Highlights:

Potential Applications:

Search Keywords: SRU80432R2Y

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Bourns

Part No:

SRU8043-2R2Y

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8504508000

COO:

ECCN:

EAR99

Reel Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
