TC33X-2-503E by bourns
Image is representational - see mfr. specs

TC33X-2-503E

Bourns

Res Trimmer 50K Ohm 25% 0.1W(1/10W) 1(Elec)/1(Mech)Turns (3.6 X 3.8mm) Footprint SMD T/R ...

Datasheet
RoHS Compliant
REEL Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

TC33X-2-503E is a 3 mm surface-mount trimming potentiometer (Trimpot) manufactured by Bourns with a rotational stop feature and a standard resistance value of 50 kO. The device features an adjustment angle of 270° ± 20° with a resistance tolerance of ±25% and contact resistance variation of 5% maximum, providing reliable precision tuning for electronic circuits. It operates over a temperature range of -40°C to +100°C with a power rating of 0.15 watts at 70°C, and exhibits a temperature coefficient of ±250 ppm/°C. The TC33X-2-503E is RoHS compliant, recommended for reflow soldering, and compatible with pick-and-place and automatic adjustment equipment, making it ideal for applications requiring compact, automated assembly and fine-tuning of circuit parameters in industrial and consumer electronics.

Search Keywords: TC33X2503E

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
TC33X-2-503E
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8533408050
COO:
CN
ECCN:
EAR99
Reel Pack: This product ships on a reel. Depending on the quantity ordered, you may receive full factory reels, cut tape (components on a strip cut from a reel), or a combination of both.
2500
Package Type:
REEL
Mounting:
Surface Mount
Number of Turns:
1(Elec),1(Mech) Turns
Termination Style:
Foot Print
Power Rating:
0.1 (1/10) W
Resistance Value:
50 KOhm
Tolerance:
25 %
Temperature Coefficient:
±250 ppm/°C
Dimension:
3 x 3.8 mm
Operating Temperature:
-40 to 100 °C
Switch Option:
No11446
Number of Elements:
111435

IN STOCK: 13,431

Ships today, if you order in

Minimum Order Quantity: 2500

Multiple: 2500

Factory Lead-Time 16 Weeks

Price (USD)

Qty
Unit Price
2,500
$0.1336
5,000
$0.1276
7,500
$0.1239
10,000
$0.1204
25,000
$0.1171
50,000
$0.1125
100,000
$0.1096
150,000 +
$0.1093
Reel Package
Log in for special pricing Click for Quote Price Match Request
