TISP4070J3BJR-S by bourns
Image is representational - see manufacturer specifications
Bourns Authorized Distributor

TISP4070J3BJR-S

Thyristor Surge Protection Devices 58V 50A 2-Pin SMB T/R ...

View Datasheet Ask the Datasheet
RoHS Compliant
REEL Packaging
Accessories
Certificate of Compliance

DESCRIPTION

TISP4070J3BJR-S is a bidirectional thyristor overvoltage protector from Bourns designed to limit overvoltages on telecom lines and enable GR-1089-CORE compliance. The device features an ion-implanted breakdown region providing precise and stable voltage with low voltage overshoot under surge conditions. It has a repetitive peak off-state voltage (VDRM) of ±58 V and a breakover voltage V(BO) of ±70 V, allowing signal voltages up to VDRM without clipping while limiting higher voltages to the breakover level. The device switches into a low on-state condition when sufficient current flows due to overvoltage, diverting current away from the protected circuit, and automatically resets when current falls below the holding current level. With a high holding current of 150 mA and rated for multiple international surge wave shapes (GR-1089-CORE, IEC 61000-4-5, TIA-968-A, ITU-T standards), it is ideal for protecting data transmission lines with DC power feeding, rugged modems, and transformer center-tap grounding applications.

Search Keywords: TISP4070J3BJRS

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
TISP4070J3BJR-S
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8541300040
COO:
GB
ECCN:
EAR99
Reel Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
3000
Package Type:
REEL
Family:
TISP4070J3
Maximum Junction Case Thermal Resistance:
N/A
Dimension:
4.57(Max) x 3.94(Max) x 2.2(Max) mm
Maximum Rate of Rise of Off-State Voltage:
5000(Min) V/ us
Maximum Breakover Current:
600 mA
Maximum Holding Current:
600 mA
Maximum Peak Pulse Current:
1000 A
Direction Type:
Bi-Directional
Maximum Junction Ambient Thermal Resistance:
90 °C/W
Maximum Breakover Voltage:
70 V

IN STOCK: 15,784

Ships today, if you order in

Minimum Order Quantity: 500

Factory Lead-Time 12 Weeks

Price (USD)

Qty
Unit Price
500
$0.5858
1,000
$0.5433
3,000
$0.5067
6,000
$0.5054
9,000
$0.4933
12,000
$0.4920
15,000
$0.4807
27,000 +
$0.4795
Reel Package
