Image is representational - see mfr. specs

AN-1307-A

Natural Aluminum Alloy Wall Mount Die Cast Aluminum Enclosure - External 8.75 x 5.75 x 2.17 Inches - Internal 8.27 x 5.29 x 1.95 Inches ...

Datasheet

RoHS Compliant

Certificate of Compliance Guarantee

360 Image

DESCRIPTION

The AN-1307-A is a NEMA die-cast aluminum enclosure designed for industrial and harsh environment applications. It features NEMA type ratings 4, 4X, 6, 6P, 12, and 13 with IP-68 equivalent protection, ensuring robust protection for enclosed equipment. The enclosure is constructed from die-cast aluminum with a natural finish (suffix -A) or smooth black powdercoat (suffix -AB), and includes a molded silicone gray gasket for environmental sealing. It is UL listed for U.S. and Canada (File #E194432) and operates reliably at temperatures up to 80°C maximum. The enclosure accepts M3.5 x 6mm or #6 x 1/4" self-tapping screws for PCB mounting and is secured with six M4x0.7 x 20mm stainless steel screws applied at 12 in./lb of torque. This enclosure is ideal for outdoor installations, corrosive environments, and applications requiring high ingress protection and structural durability.

Product Highlights:

Potential Applications:

Search Keywords: AN1307A

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Bud Industries

Part No:

AN-1307-A

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

7612905000

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
