N3R-5808

The N3R-5808 is a NEMA 3R rated electrical enclosure constructed from 16 gauge galvanized steel for outdoor applications. ...

Datasheet

RoHS Compliant

Certificate of Compliance Guarantee

DESCRIPTION

The N3R-5808 is a NEMA 3R rated electrical box designed to house and protect sensitive components in outdoor or indoor environments where dripping water is a concern. Constructed from durable 16 gauge galvanized steel with a spot-welded body, it features an ASA-70 light gray powdercoat finish for corrosion resistance. The enclosure includes a 16 gauge zinc-plated internal panel, a 6mm thick black neoprene gasket for sealing, and a riveted-on padlockable draw latch for security. For wiring access, it is equipped with three double knockouts for 3/4" and 1" conduits and two double knockouts for 1/2" and 3/4" conduits. This enclosure is ideal for housing controls, instruments, or junction boxes that require protection from rain, sleet, and external ice formation.

Product Highlights:

Potential Applications:

Search Keywords: N3R5808

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Bud Industries

Part No:

N3R-5808

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8538908180

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
