Image is representational - see mfr. specs

PN-1325-C

Light Gray Polycarbonate Wall Mount NEMA 4X Enclosure - External 8.74 x 5.75 x 2.17 Inches - Internal 8.5 x 5.51 x 1.99 Inches ...

Datasheet

RoHS Compliant

Certificate of Compliance Guarantee

360 Image

DESCRIPTION

PN-1325-C is a NEMA 4X rated polycarbonate enclosure featuring a light gray body with a clear cover for visual inspection of internal components. The enclosure is constructed from UV stabilized polycarbonate material with UL94-HB flammability rating (UL File #E41613) and operates over a service temperature range of -40°C to +120°C. It includes a clear silicone gasket for sealing and four mounting bosses with M3 × 0.188" long threaded inserts, with hardware kit containing six M4 × 20mm screws for assembly. The enclosure dimensions include an overall length of 8.740 mm and width of 5.740 mm with ±0.015 tolerance on dimensions unless otherwise specified. This enclosure is ideal for industrial control, instrumentation, and outdoor applications requiring environmental protection and component visibility.

Product Highlights:

Potential Applications:

Search Keywords: PN1325C

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Bud Industries

Part No:

PN-1325-C

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8538100000

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
