ALTERNATIVE PRODUCTS
Older Equivalent
FFF-27917000
FFF-27917000

In Stock: 250

Minimum Order: 20

VIEW PRODUCT
2FB53-78/TABS by carling technologies
Image is representational - see mfr. specs

2FB53-78/TABS

Carling Technologies

Switch Toggle ON None ON SPDT Bat Lever Quick Conn 15A 250VAC 559.27VA Panel Mount with Threads ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 2FB53-78/TABS is a single pole toggle switch from Carling Technologies' F-Series designed for general-purpose applications requiring reliable switching control. This switch features an On-None-On circuit configuration with a sealed bat-style actuator (78 designation), 0.687 inch toggle length, and 0.465 inch bushing length, equipped with 0.250 inch tab quick-connect terminals. The switch is rated to 20A 27VAC and is suitable for low voltage 12/24V DC applications, with a dielectric strength of 1000V between live and dead metal parts. It delivers 50,000 electrical cycles in maintained operation and 25,000 cycles in momentary mode, with a mechanical life of 100,000 cycles and an operating temperature range from 0°F to 150°F (-17.8°C to +65.6°C). This versatile switch is commonly used in marine, food service, generator, industrial control, and office automation applications where durable, reliable switching is essential.

Search Keywords: 2FB5378TABS

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Carling Technologies
Part No:
2FB53-78/TABS
Alias/AKA:
FFF-27917000
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509040
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
20
Pole Throw Configuration:
1P2T (SPDT)
Switch Configuration:
On None On
Contact Rating @ Voltage:
559.27 A
Actuator Style:
Bat Lever
Mounting:
Panel Mount with Threads
Thread Size:
15/32-32
Body Orientation:
Straight
Terminal Type:
Quick Connect
Dimension:
28.8 x 16.1 x 57.37 mm
Operating Temperature:
-17.8 to 65.6 °C

IN STOCK: 250

Can Ship immediately

Minimum Order Quantity: 20

Multiple: 20

Factory Lead-Time 8 Weeks

Price (USD)

Qty
Unit Price
20
$10.92
40
$10.82
60
$10.73
100
$10.68
260
$10.65
500
$10.30
1,000 +
$10.03
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides
