CA2-B0-34-615-121-C by carling technologies
Image is representational - see manufacturer specifications
Carling Technologies Authorized Distributor

CA2-B0-34-615-121-C

A C-Series two-pole, 15A hydraulic-magnetic circuit breaker featuring a series trip circuit and a medium time delay for DC and 50/60Hz applications. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The CA2-B0-34-615-121-C is a C-Series hydraulic-magnetic circuit breaker designed for overcurrent protection. This two-pole device features a series trip (current) circuit with a 15A rating and a medium time delay suitable for both DC and 50/60Hz systems. It is configured with a handle actuator for each pole, 10-32 stud terminals for secure connections, and uses a 6-32 threaded insert for mounting. As part of a series known for handling higher amperage in a smaller package, this UL Recognized and CSA Accepted breaker is ideal for applications in marine, telecom, military, and renewable energy systems.

Search Keywords: CA2B034615121C

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Carling Technologies
Part No:
CA2-B0-34-615-121-C
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536200020
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
10
Type:
Hydraulic Magnetic
Voltage Rating:
277,480 VAC
Number of Poles:
2
Current Rating:
15 A
Terminal Design:
Stud
Operating Temperature:
N/A
Mounting:
Panel Mount

IN STOCK: 0

MOQ for out of Stock Qty: 3

Factory Lead-Time 6 Weeks

Price (USD)

Qty
Unit Price
3
$91.19
5
$82.06
8
$71.81
10 +
$70.37
