RM1E23AA25 by carlo gavazzi
Image is representational - see manufacturer specifications
Carlo Gavazzi Authorized Distributor

RM1E23AA25

Solid State Relay - SPST - 25 A - 280 VAC - Panel - Screw - Zero Crossing ...

View Datasheet Ask the Datasheet
RoHS Compliant
EACH Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The RM1E23AA25 is a 1-pole AC Solid-state Relay, RM series. The analogue switching relay works in accordance with the phase angle control principle, i.e., the output switching point in the AC sine wave depends on the control input which can be either 4 to 20mA or 0 to 10VDC. 4mA or 0VDC correspond to zero output power whilst 20mA or 10VDC correspond to full output power (near linear power response). The relay switches off every time the output current crosses zero and switches ON in accordance with the applied control input. Polarized lockable control connector for safe connection for voltage controlled version. Analog switching Variable intensity LED-indication according to input current Integral snubber network Applications Industrial, Power Management, Automation & Process Control

Search Keywords: RM1E23AA25

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Carlo Gavazzi
Part No:
RM1E23AA25
Alias/AKA:
RM1E23AA25
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8535908085
COO:
CN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
5
Package Type:
EACH
Output Type:
AC
Maximum Output Voltage:
280 V
Maximum Output Current:
25(RMS) A
Output Device:
N/A
Input Type:
DC
Input Voltage:
0 - 10 V
Mounting:
Screw
Circuit Arrangement:
N/A
Dimension:
44.8 x 58.2 x 28.8 mm

IN STOCK: 72

Ships today, if you order in

Factory Lead-Time 14 Weeks

Price (USD)

Qty
Unit Price
1
$139.46
5
$137.19
10
$129.68
20
$129.36
50
$122.86
100 +
$122.55
Supplier's Standard Package
Log in for special pricing

Tools/3D Models

Product Guides
