RP1A23D5 by carlo gavazzi
Image is representational - see mfr. specs

RP1A23D5

Carlo Gavazzi

SSR RP ZS 230V 5A DC IP ...

Datasheet
RoHS Compliant
EACH Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

RP1A23D5 is a 1-phase AC solid state relay designed for PCB mounting, providing an ideal interface between logic controls and AC loads. It features zero-cross switching mode with a rated operational voltage of 230 VACrms, blocking voltage of 650 Vp, and rated operational current of 5 AACrms. The relay accepts a DC control voltage of 3 to 32 VDC with opto-isolation greater than 4000 VACrms for reliable signal isolation. Built with surface mount technology and flexible encapsulation for extended life, it operates within a temperature range of -20°C to +70°C. Common applications include switching heaters, motors, lights, valves, and solenoids in industrial control systems.

Search Keywords: RP1A23D5

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Carlo Gavazzi
Part No:
RP1A23D5
Alias/AKA:
RP1A23D5
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8535908085
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
10
Package Type:
EACH
Output Type:
AC
Maximum Output Voltage:
265(RMS) V
Maximum Output Current:
5 A
Output Device:
N/A
Input Type:
DC
Input Voltage:
32 V
Mounting:
Through Hole
Circuit Arrangement:
N/A
Dimension:
43 x 0.5 x 25.4 mm

IN STOCK: 181

Ships today, if you order in

Minimum Order Quantity: 10

Multiple: 10

Factory Lead-Time 14 Weeks

Price (USD)

Qty
Unit Price
10
$21.27
30
$20.85
50
$19.76
100
$19.10
250
$19.04
500
$18.99
1,000 +
$18.95
