50-10A-20 by cinch / cinch connectivity solutions
Image is representational - see mfr. specs

50-10A-20

Cinch / Cinch Connectivity Solutions

Conn Card Edge SKT 10 POS 3.96mm Solder Lug ST Panel Mount ...

Datasheet
RoHS Compliant
Packaging
Accessories
Discontinued
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 50-10A-20 is a commercial-grade edge connector featuring solder eyelet termination with 10 contact positions at .156" (3.96mm) density. It is designed to accept single or double-sided .062" (1.59mm) thick PC boards and utilizes bifurcated semi-bellows contacts for enhanced contact reliability in demanding environments. The connector operates over a temperature range of -65°C to +105°C, with a current rating of 5 Amps per contact and a withstanding voltage of 1800 VAC rms at sea level. The contacts are constructed from spring brass with gold plating over nickel, and the insulation material is UL 94V-0 rated glass-filled polyester. This connector is ideal for applications involving vibration or board irregularities, meeting applicable performance criteria of MIL-C-21097, and is commonly used in industrial and commercial equipment requiring reliable edge-card connections.

Search Keywords: 5010A20

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Cinch / Cinch Connectivity Solutions
Part No:
50-10A-20
Alias/AKA:
2501050307
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536698000
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Type:
Card Edge
Body Orientation:
Straight
Mounting:
Panel Mount
Termination Method:
Solder
Card Thickness:
1.8 mm
Pitch:
3.96 mm
Number of Contacts:
10
Operating Temperature:
-65 to 105 °C
Life Cycle:
Discontinued
  This product is discontinued, but still in stock

IN STOCK: 1,381

Ships today, if you order in

Minimum Order Quantity: 25

Price (USD)

Qty
Unit Price
25
$12.84
50
$12.07
100
$11.35
250
$10.66
500
$10.38
1,000 +
$10.22
