CA-10IDS2-F by circuit assembly corp.
Image is representational - see mfr. specs

CA-10IDS2-F

Circuit Assembly Corp.

IDC Socket Connector 10 Position ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

CA-10IDS2-F is a 10-position insulation displacement connector (IDC) socket manufactured by Circuit Assembly Corp that conforms to MIL-C-83503/7C specifications. The connector features single leaf side wipe contacts made of beryllium copper with 30 microinches of gold plating in the contact area, designed to mate with 0.025" square or round posts and mass-terminate with 0.050" center cable. It operates over a temperature range of -55°C to +120°C with a current rating of 1 AMP and dielectric withstanding voltage of 500 Vrms minimum. The insulator is constructed from glass-filled polyester (UL94V-0) with contact insertion force of 4 oz typical and extraction force of 2.75 oz typical. Optional features include polarizing tabs, strain relief, and pull tabs, making it suitable for applications requiring reliable interconnection in industrial, telecommunications, and data acquisition systems.

Search Keywords: CA10IDS2F

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Circuit Assembly Corp.
Part No:
CA-10IDS2-F
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
140

IN STOCK: 350

Ships today, if you order in

MOQ for In Stock Qty: 5

MOQ for out of Stock Qty: 5

Factory Lead-Time 8 Weeks

Price (USD)

Qty
Unit Price
5
$5.56
25
$5.28
100
$5.02
175
$4.77
350
$2.94
525
$2.32
700 +
$2.28
Log in for special pricing Click for Quote Price Match Request
