PANEL JACK - METAL THREAD ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 09-9072-1-0319 is a metal thread-mount panel jack designed for vertical mounting on boards and panels up to 3/16" thickness. It features a brass body (ASTM B16, Alloy C36000, 1/2 hard) with a beryllium copper spring cage (ASTM B194, Alloy C17200) for reliable electrical contact and durability. The jack accepts a 0.000" ± 0.001" pin/plug/jack size and mounts via 1/4-32 UNEF-2A thread with a 0.257" ± 0.002" mounting hole, providing a minimum hole depth of 0.420" and an overall length of 0.922". The nylon insulation (ASTM D4066) is available in multiple color options, and the assembly includes a phosphor bronze washer and brass nut for secure panel mounting. This jack is RoHS compliant and ideal for applications requiring precision-machined connectors in instrumentation, telecommunications, and industrial equipment where reliable signal transmission and mechanical stability are essential.

Search Keywords: 09907210319

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Concord
Part No:
09-9072-1-0319
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
ECCN:
EAR99
