6280-6PG-3DC by conxall
Image is representational - see manufacturer specifications
Conxall Authorized Distributor

6280-6PG-3DC

The 6280-6PG-3DC is a Mini-Con-X series 6-contact, field-installable cable end connector with #20 crimp-style pin contacts and a daisy chain grommet backshell. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 6280-6PG-3DC is a field-installable cable end connector from the Mini-Con-X® series. It is configured with six #20 pin contacts that are gold-plated over nickel and designed for a crimp termination style. This connector features a Style 3 backshell with a "daisy chain" grommet, which has three internal diameters (.125", .188", and .250") to accommodate various cable sizes. The backshell provides a weathertight grommet grip and seal, complemented by an interfacial "O" ring for enhanced environmental protection. This connector is suitable for a wide range of indoor and outdoor industrial and electronic applications where a reliable and robust connection is required.

Search Keywords: 62806PG3DC

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Conxall
Part No:
6280-6PG-3DC
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694020
COO:
US
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
100

IN STOCK: 55

Ships today, if you order in

Minimum Order Quantity: 5

Factory Lead-Time 6 Weeks

Price (USD)

Qty
Unit Price
5
$8.70
25
$8.43
50
$8.30
100
$8.18
300
$7.98
500
$6.82
1,000 +
$6.37
Supplier's Standard Package
Log in for special pricing
