150105J100IC by cornell dubilier
Image is representational - see mfr. specs

150105J100IC

Cornell Dubilier

Metalized Polyester Capacitor - Axial - Non Inductive - 1uF (+/-) 5% - 100VDC - 0.394 in Dia x 0.807 in ...

Datasheet
RoHS Compliant
BAG Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 150105J100IC is a 1.0 µF axial leaded metallized polyester capacitor rated for 100 Vdc operation. This Type 150 series capacitor features a non-inductive wound design with flame retardant outer wrap meeting UL510 and epoxy end fill meeting UL94V-0 standards. The device has a body diameter of 10.0 mm (0.394 inches) and a length of 20.5 mm (0.807 inches) with 0.8 mm diameter tinned copper leads spaced 40 mm apart. It operates across a temperature range of -55 °C to +125 °C with capacitance tolerance of ±5%, ±10%, or ±20%, and exhibits a maximum DC leakage current of 0.3CV or 10 µA (whichever is greater) after 3 minutes at rated voltage. This capacitor is ideal for blocking, bypass, decoupling, smoothing, and timing applications in electronic circuits, available in bulk or on tape and reel for automatic insertion.

Search Keywords: 150105J100IC

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Cornell Dubilier
Part No:
150105J100IC
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8532250060
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
200
Package Type:
BAG
Dielectric:
PET
Voltage:
100,63 VDC|VAC
Capacitance Value:
1 uF
Tolerance:
5 %
Mounting:
Through Hole
Termination Style:
Axial
Size:
10 x 20.5 mm

IN STOCK: 986

Can Ship immediately

Minimum Order Quantity: 25

Factory Lead-Time 18 Weeks

Price (USD)

Qty
Unit Price
25
$1.65
200
$1.47
400
$1.44
600
$1.42
1,000
$1.38
2,600
$1.37
5,000
$1.35
7,600 +
$1.34
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
