380LQ821M400A052 by cornell dubilier
Image is representational - see mfr. specs

380LQ821M400A052

Cornell Dubilier

Aluminum Electrolytic Capacitor - 820uF ±20% - 400V - 85°C - Through Hole Snap-In - 50mm x 35mm Dia. ...

Datasheet
RoHS Compliant
CARTON Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 380LQ821M400A052 is a Type 380LQ compact, high-capacitance snap-in aluminum electrolytic capacitor designed for 85°C operation at 400 Vdc (450 Vdc surge). This capacitor features 820 µF nominal capacitance with a maximum ESR of 0.243 ohms at 120 Hz and 0.122 ohms at 20 kHz, measured at +25°C. The unit is housed in a 35 mm diameter by 50 mm length case and is rated for ripple currents of 3.25 A at 120 Hz and 4.14 A at 20 kHz when operating at +85°C. The Type 380LQ design achieves approximately 27% smaller size and more than 10 mm shorter length compared to the Type 380LX, enabling equipment size reduction while maintaining original performance specifications. These capacitors are commonly used in power supplies, industrial equipment, and high-reliability applications requiring compact form factors with high capacitance density.

Search Keywords: 380LQ821M400A052

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Cornell Dubilier
Part No:
380LQ821M400A052
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8532220040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
80
Package Type:
CARTON
Capacitance Value:
820 uF
Tolerance:
20 %
Operating Temperature:
-25 to 85 °C
Mounting:
Through Hole
Voltage:
400 VDC

IN STOCK: 185

Can Ship immediately

Minimum Order Quantity: 5

Factory Lead-Time 20 Weeks

Price (USD)

Qty
Unit Price
5
$10.39
25
$9.41
80
$8.25
160
$7.86
320
$7.77
560
$7.54
1,040 +
$7.45
Suppliers Standard Package
