381LQ471M450A452 by cornell dubilier
Image is representational - see manufacturer specifications
Cornell Dubilier Authorized Distributor

381LQ471M450A452

A 470 µF, 450 Vdc snap-in aluminum electrolytic capacitor designed for high ripple current applications with a 105 °C operating temperature. ...

View Datasheet Ask the Datasheet
RoHS Compliant
BOX Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 381LQ471M450A452 is a Type 381LQ snap-in aluminum electrolytic capacitor designed for high-performance applications. It offers a capacitance of 470 µF with a ±20% tolerance and a rated voltage of 450 Vdc, with a surge capability of 500 Vdc. Key technical characteristics include a low maximum ESR of 0.388 ohms at 120 Hz and a high ripple current rating of 1.74 A at 105°C. This capacitor operates over a temperature range of -25 °C to +105 °C and has an endurance life of 2000 hours at full load. Its compact 35 x 45 mm case size and high ripple capability make it ideal for power supply filtering and other applications where space is limited but high performance is required.

Search Keywords: 381LQ471M450A452

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Cornell Dubilier
Part No:
381LQ471M450A452
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8532220040
COO:
CN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
40
Package Type:
BOX
Capacitance Value:
470 uF
Tolerance:
20 %
Operating Temperature:
-25 to 105 °C
Mounting:
Through Hole
Voltage:
450 VDC

IN STOCK: 646

Ships today, if you order in

Minimum Order Quantity: 5

Factory Lead-Time 28 Weeks

Price (USD)

Qty
Unit Price
5
$6.67
40
$6.40
80
$6.36
120
$6.33
280
$6.32
520
$6.30
1,000 +
$6.29
