940C20P1K-F by cornell dubilier
Image is representational - see mfr. specs

940C20P1K-F

Cornell Dubilier

Polypropylene Film Capacitors - Axial - 0.1uF (+/-) 10% - 2000VDC - RoHS ...

Datasheet
RoHS Compliant
BAG Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 940C20P1K-F is a Type 940 polypropylene film capacitor designed for high-voltage pulse and snubber applications, rated at 2000 Vdc (500 Vac). This capacitor features dual metallized electrodes that provide self-healing properties and exceptional peak current carrying capability, with a dV/dt rating of 1712 V/µs. The device has a capacitance of 0.11 µF with ±10% tolerance, dimensions of 21.0 mm diameter by 34.0 mm length, and exhibits low ESR of 7 mO at 100 kHz with an ESL of 24 nH. It delivers a peak current of 171 A and an RMS current of 8.3 A at 100 kHz and 70°C. The capacitor operates reliably across a temperature range of -55°C to 105°C and is ideal for high-frequency switching circuits, power conversion systems, and electromagnetic interference suppression where high voltage and rapid voltage transients are present.

Search Keywords: 940C20P1KF

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Cornell Dubilier
Part No:
940C20P1K-F
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8532250060
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
25
Package Type:
BAG
Dielectric:
PP
Voltage:
2000,630 VDC|VAC
Capacitance Value:
0.1 uF
Tolerance:
10 %
Mounting:
Through Hole
Termination Style:
Axial
Size:
21 x 34 mm

IN STOCK: 525

Can Ship immediately

Minimum Order Quantity: 25

Multiple: 25

Factory Lead-Time 28 Weeks

Price (USD)

Qty
Unit Price
25
$4.50
50
$4.36
100
$4.16
250
$4.05
500
$3.82
1,000
$3.72
2,500
$3.63
5,000 +
$3.57
Suppliers Standard Package
