MLP111M450EK1A

Name: MLP111M450EK1A
Brand: Cornell Dubilier
SKU: 43855300
Price: 517.24 USD
Availability: InStock

FlatPack Tabbed ALUMINUM ELECTROLYTIC CAPACITOR MLP 450V 110muF ±20% 1.500Lx1.750W 38.10mmx44.45mm ...

View Datasheet

Ask the Datasheet

RoHS Compliant

TRAY Packaging

DESCRIPTION

MLP111M450EK1A is a Type MLP 85°C FlatpackTM ultra-long-life aluminum electrolytic capacitor designed for high-voltage applications requiring compact form factors and extended operational life. This 110 µF capacitor operates at a rated voltage of 450 Vdc (500 Vdc surge) with an operating temperature range of -55°C to +85°C, delivering exceptional energy storage in a very low-profile package measuring 1.5 inches in length and 0.50 inches maximum height. The capacitor features a maximum ESR of 565 mO at 25°C (120 Hz) and supports a ripple current of 0.96 A at 85°C case temperature (20 kHz), with the capability to double ripple current performance when attached to an external heatsink. With a nearly hermetic welded seal design, the MLP111M450EK1A is engineered to deliver 50 years of operational life at +45°C and withstands altitudes exceeding 80,000 feet, making it ideal for military SEM-E modules, telecom circuit packs, and computer cards requiring reliable voltage holdup and filtering in demanding environments.

Product Highlights:

Potential Applications:

Search Keywords: MLP111M450EK1A

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Cornell Dubilier

Part No:

MLP111M450EK1A

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8532220055

COO:

ECCN:

EAR99

Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
