SCRN236R-F by cornell dubilier
Image is representational - see mfr. specs

SCRN236R-F

Cornell Dubilier

The SCRN236R-F is a 5 µF, 1000 Vpk film-paper commutating capacitor designed for high peak and RMS current SCR applications. ...

Datasheet
RoHS Compliant
CARTON Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The SCRN236R-F is a film-paper/extended foil commutating capacitor intended for SCR (silicon controlled rectifier) applications. It features a capacitance of 5 µF with a ±10% tolerance and a peak voltage rating of 1000 Vpk. This capacitor is capable of handling a maximum RMS current of 60 A and has a maximum VA rating of 1785 at 65°C. With an operating temperature range of –40 ºC to +80 ºC and a life expectancy of 40,000 hours, it ensures reliability in demanding environments. Housed in a 'B' code metal case, it is ideal for high-frequency and pulsed applications requiring high current and voltage capability.

Search Keywords: SCRN236RF

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Cornell Dubilier
Part No:
SCRN236R-F
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8532100000
COO:
US
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
5
Package Type:
CARTON
Dielectric:
Paper
Voltage:
1000 VDC
Capacitance Value:
5 uF
Tolerance:
10 %
Mounting:
N/A
Termination Style:
Screw Terminal
Size:
68.326 x 39.624 x 107.95 mm

IN STOCK: 13

Can Ship immediately

Manufacturer Stock: 100   can ship 5/4/26

Factory Lead-Time 48 Weeks can ship 3/24/27

Price (USD)

Qty
Unit Price
1
$130.71
5
$120.95
10
$115.77
20
$111.01
50
$80.97
100 +
$67.48
Suppliers Standard Package
