DESCRIPTION

TBR2U-220A is a single shot timer designed for precise timing control applications. It features a multi timing range from 0.1 seconds to 10 hours with six selectable time ranges via front panel switches, and operates on dual voltage input of 220 VAC or 24 VAC/DC. The timer includes a DPDT relay output rated at 10 A AC resistive and 8 A DC resistive, with a maximum switching voltage of 250 VAC/VDC and transient protection of 2500 volts. Additional features include LED power ON and relay indicators, direct reading capability, and a repetition accuracy of ±0.2% at constant ambient temperature. This timer is suitable for industrial automation, process control, and equipment sequencing applications where reliable timing and robust relay output are required.
