742C083472JP by cts corporation

742C083472JP

CTS Corporation

Res Thick Film Array 4.7K Ohm 5% 0.25W(1/4W) ±200ppm/°C ISOL 8-Pin 1206(4 X 0603) Concave SMD T/R ...

Datasheet
RoHS Compliant
Reel Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The CTS 742C083472JP is a compact, surface-mountable resistor array designed for optimal performance in various electronic applications. This resistor array offers a resistance value of 4.7K Ohms with a tolerance of 5%. It features a power rating of 0.25W (1/4W) and a temperature coefficient of ±200ppm/°C.The 742C083472JP is built with a thick film technology, which ensures high reliability and stability in operation. It is constructed in an 8-pin 1206 package, featuring a concave shape that allows for easy soldering and space-saving on PCBs. The array consists of four separate resistors, each with a size equivalent to 0603, allowing for precise and flexible circuit design.Furthermore, this resistor array offers electrical isolation between resistors, preventing any interference or cross-talk that might occur during operation. It is supplied in tape and reel packaging, suitable for automated assembly processes, ensuring ease of integration into various electronic devices.Overall, the CTS 742C083472JP is a versatile and reliable resistor array that provides excellent performance and convenience in a compact package, making it an ideal choice for a wide range of electronic applications.

Search Keywords: 742C083472JP

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
CTS Corporation
Part No:
742C083472JP
RoHS:
Yes
HTS:
8533100020
COO:
JP
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
25000
Package Type:
Reel
Case Size:
1206
Circuit Designator:
ISOL
Number of Resistors:
4
Number of Terminals:
8
Power Rating:
0.25 (1/4) W
Power Rating per Resistor:
0.063 (1/16) W
Resistance Value:
4.7 KOhm
Tolerance:
5 %
Temperature Coefficient:
±200 ppm/°C
Termination Style:
Concave

IN STOCK: 15,000

Can Ship immediately

On Order: 25,000   can ship 4/29/26

Minimum Order: 7500

Factory Lead-Time 24 Weeks

Price (CAD)

Qty
Unit Price
7,500
$0.0474
25,000
$0.0456
50,000
$0.0445
100,000
$0.0433
150,000
$0.0427
250,000
$0.0420
500,000 +
$0.0410
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
