MP040 by cts corporation
Image is representational - see manufacturer specifications

MP040

CTS Corporation

Crystal 4MHz ±30ppm (Tol) ±50ppm (Stability) 20pF FUND 100Ohm 2-Pin HC-49 Thru-Hole Bulk ...

Datasheet
RoHS Compliant
BULK Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

MP040 is a 4.0 MHz quartz crystal designed for fundamental mode operation with an 18 pF load capacitance, housed in a standard HC-49/U metal package. The crystal features an AT-cut design with a frequency tolerance of ±30 ppm at +25°C and frequency stability of ±50 ppm over the operating temperature range. It exhibits a series resistance of 100 O and a maximum shunt capacitance of 7.0 pF, with drive level capability of 100–1000 µW. The MP040 is ideal for applications in wireless communications, FPGA/microcontrollers, computer peripherals, and consumer electronics requiring stable timing references with proven reliability in commercial and industrial environments.

Search Keywords: MP040

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
CTS Corporation
Part No:
MP040
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8541600030
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
BULK
Standard Frequency:
4 MHz
Load Capacitance:
20 pF
Frequency Tolerance:
±30 ppm
Supplier Package:
HC-49
Operating Temperature:
-20 to 70 °C

IN STOCK: 3,075

Can Ship immediately

On Order: 5,000   can ship 10/28/26

Minimum Order Quantity: 100

Multiple: 100

Factory Lead-Time 16 Weeks

Price (USD)

Qty
Unit Price
100
$0.7743
300
$0.7284
1,000
$0.6780
2,500
$0.6397
5,000
$0.5221
7,500
$0.5078
10,000
$0.4673
15,000 +
$0.4539
Supplier's Standard Package
