GBP-6 by curtis industries
Image is representational - see mfr. specs

GBP-6

Curtis Industries

Conn Barrier Strip 6 POS 11.11mm Solder ST Thru-Hole 20A ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

GBP-6 is a 6-terminal printed circuit board terminal block designed for feed-thru and surface connection applications. It features precision screw-machined brass inserts molded in place with .062" diameter tin-plated brass pins, providing reliable electrical connections for wire termination. The block is constructed from black thermo-set phenolic material with a continuous use temperature rating of 150°C (302°F) and UL 94 HB flammability rating. With a current rating of 20 amps (UL/CSA) and voltage ratings up to 300 volts (CSA) or 250 volts (UL commercial applications), the GBP-6 is ideal for sub-chassis, thru-panel, and printed circuit board applications requiring durable, break-resistant terminal connectivity. The terminal spacing of 11.11 mm center-to-center and overall dimensions of 3.437 inches (87.31 mm) make it suitable for compact industrial and commercial electrical assemblies.

Search Keywords: GBP6

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Curtis Industries
Part No:
GBP-6
Alias/AKA:
266606000
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536904000
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
200
Type:
Barrier Strip
Mounting:
Through Hole
Gender:
N/A
Termination Method:
Solder
Pitch:
11.11 mm
Number of Circuits:
6
Maximum Voltage Rating:
600 V
Maximum Current Rating:
20 A
Wire Size:
12-22 AWG
Operating Temperature:
150(Max) °C

IN STOCK: 115

Can Ship immediately

MOQ for In Stock Qty: 5

MOQ for out of Stock Qty: 50

Factory Lead-Time 5 Weeks

Price (USD)

Qty
Unit Price
5
$9.12
10
$9.08
25
$9.06
50
$9.04
100
$6.78
150
$6.33
200 +
$6.20
Suppliers Standard Package
