GBSX-5 by curtis industries
Image is representational - see mfr. specs

GBSX-5

Curtis Industries

The GBSX-5 is a 5-terminal, closed-back terminal block with a thermoplastic housing, unplated brass inserts, and a 7/16-inch center-to-center spacing. ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The GBSX-5 is a 5-terminal, closed-back terminal block from the GB series, featuring a thermoplastic polyphenylene oxide housing. It is rated for 20 amps and has multiple UL voltage ratings up to 600V for limited energy applications, with a CSA rating of 300V. The block accepts wire sizes from #22 to #12 AWG using No. 6-32 screws with a recommended tightening torque of 9 in-lb. Key characteristics include a continuous use temperature of 110°C, a UL 94V-0 flammability rating, and a typical terminal-to-terminal breakdown voltage of 5,800V. Its closed-back design allows for direct mounting on metal surfaces without additional insulation, making it ideal for various industrial and commercial wiring applications.

Search Keywords: GBSX5

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Curtis Industries
Part No:
GBSX-5
Alias/AKA:
269735000
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536904000
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
200
Type:
Barrier Strip
Mounting:
Panel Mount
Gender:
N/A
Termination Method:
Screw
Pitch:
11.11 mm
Number of Circuits:
5
Maximum Voltage Rating:
600 V
Maximum Current Rating:
20 A
Wire Size:
12-22 AWG
Operating Temperature:
150(Max) °C

IN STOCK: 240

Can Ship immediately

MOQ for In Stock Qty: 5

MOQ for out of Stock Qty: 50

Factory Lead-Time 5 Weeks

Price (USD)

Qty
Unit Price
5
$8.91
10
$7.06
25
$6.17
50
$5.77
100
$5.71
150
$5.53
200 +
$5.47
Suppliers Standard Package
