Image is representational - see manufacturer specifications
Curtis Industries Authorized Distributor

L-4

Barrier Block - 600V 100A - 1.16in (29.6mm) - 1/4-20 Screws - 4 Sections ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

L-4 is a 4-pole Type L barrier style terminal block designed for high voltage and current applications in machine, switchboard, and other heavy load terminations. It features a nickel-plated brass terminal bar with 1/4"-20 plated round-head steel screws and accepts wire up to No. 1AWG. The terminal block is rated at 100A/600V with a tightening torque of 50 in.-lb. and is housed in a phenolic material with a continuous use temperature of 150°C and 94V-1 flammability rating. UL recognized and CSA certified, this terminal block offers breakdown voltages of 11,000V typical terminal-to-terminal and 9,700V typical terminal-to-ground. It is ideal for branch circuit termination and can be combined with other terminal block types for flexible design configurations.

Search Keywords: L4

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Curtis Industries
Part No:
L-4
Alias/AKA:
268004000
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536904000
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Type:
Cover
Dimension:
156.43 x 63.5 x 47.62 mm
Operating Temperature:
N/A

IN STOCK: 58

Ships today, if you order in

Factory Lead-Time 3 Weeks

Price (USD)

Qty
Unit Price
1
$52.30
5
$48.91
10
$47.45
25
$45.52
50
$44.06
100
$42.60
250 +
$40.67
Supplier's Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides

Accessories

268A158-4

Terminal Block Cover - For L Series - 4 Positions
