7506K4 by cutler-hammer / eaton

7506K4

Cutler-Hammer / Eaton

Switch Toggle OFF None (ON) SPST Round Lever Screw 10A 250VAC 372.85VA Panel Mount with Threads ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 7506K4 is a general-purpose AC-rated toggle switch manufactured by Cutler Hammer/Eaton, designed for applications requiring momentary-on switching capability. It features a 10A, 250 Vac rating with a 1PST (single-pole, single-throw) configuration, offering OFF in the up position and momentary-on in the down position. The switch includes screw terminals for secure electrical connections and has a bushing length of 0.469 inches (11.91 mm) with a lever length of 0.563 inches (14.30 mm). This compact design with standard mounting dimensions makes it suitable for control panels, industrial equipment, and commercial applications where reliable momentary switching is required.

Search Keywords: 7506K4

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Cutler-Hammer / Eaton
Part No:
7506K4
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509065
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Pole Throw Configuration:
1P1T (SPST)
Switch Configuration:
OFF None (ON)
Contact Rating @ Voltage:
372.85 A
Actuator Style:
Round Lever
Mounting:
Panel Mount with Threads
Thread Size:
15/32-32
Body Orientation:
Straight
Terminal Type:
Screw
Dimension:
30.93 x 15.87 x 52.8 mm
Operating Temperature:
-17.8 to 65.6 °C

IN STOCK: 90

Ships today, if you order in

Minimum Order Quantity: 5

Factory Lead-Time 12 Weeks

Price (USD)

Qty
Unit Price
5
$9.66
25
$8.76
50
$8.36
100
$8.12
300
$7.67
500
$7.47
1,000 +
$7.37
Suppliers Standard Package
