7803K12 by cutler-hammer / eaton

7803K12

Cutler-Hammer / Eaton

Switch Toggle ON OFF ON DPDT Round Lever Solder Lug 20A 250VAC 745.7VA Panel Mount with Threads ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

This CUTLER HAMMER/EATON part 7803K12 is a versatile and durable toggle switch that features a Double Pole Double Throw (DPDT) configuration with an ON OFF ON function. The switch has a round lever design, making it easy to operate, and comes equipped with solder lugs for secure and reliable connections. With a high current rating of 20A at 250VAC and 745.7VA, this switch is suitable for a wide range of applications. The panel mount design with threads ensures easy installation and secure mounting.

Search Keywords: 7803K12

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Cutler-Hammer / Eaton
Part No:
7803K12
RoHS:
Yes
HTS:
8536509065
COO:
MX
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Pole Throw Configuration:
2P2T (DPDT)
Switch Configuration:
On Off On
Contact Rating @ Voltage:
745.7 A
Actuator Style:
Round Lever
Mounting:
Panel Mount with Threads
Thread Size:
15/32-32
Body Orientation:
Straight
Terminal Type:
Solder
Operating Temperature:
-17.8 to 65.6 °C

IN STOCK: 48

Ships today, if you order in

On Order: 100   can ship 1/28/26

Minimum Order: 5

Factory Lead-Time 12 Weeks

Price (USD)

Qty
Unit Price
5
$10.043
25
$9.311
50
$9.229
100
$9.177
250
$9.136
500
$9.085
1,000 +
$9.043
