8809K16 by cutler-hammer / eaton
Image is representational - see mfr. specs

8809K16

Cutler-Hammer / Eaton

Switch Toggle - ON OFF (ON) - SPDT - Round Lever - Screw - 20A - 115VAC - 28VDC - Panel Mount with Threads. ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 8809K16 is a general-purpose toggle switch designed for AC/DC rated applications with a 1PDT (single-pole double-throw) contact configuration. It features maintained toggle action with quick-make/quick-break wiping contact mechanism using bronze silver-plated contacts to ensure reliable switching performance. The switch is rated at 6A, 125 Vac/Vdc and includes screw terminals (brass, designed to accept #5-40 x 5/32 in screws) for secure wiring connections. The base is constructed from thermostat molding material with a threaded bushing (0.468 in diameter, 32 threads/inch) and keyway anti-rotation feature. It operates reliably across a temperature range of 0°F to 150°F (-17.8°C to 65.6°C) and is commonly used in small motor applications, control panels, and general-purpose switching circuits where both AC and DC operation is required.

Search Keywords: 8809K16

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Cutler-Hammer / Eaton
Part No:
8809K16
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509065
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Pole Throw Configuration:
1P2T (SPDT)
Switch Configuration:
ON OFF (ON)
Contact Rating @ Voltage:
20@28VDC A
Actuator Style:
Round Lever
Mounting:
Panel Mount with Threads
Thread Size:
15/32-32
Body Orientation:
Straight
Terminal Type:
Screw
Dimension:
28.45 x 15.75 x 55.76 mm
Operating Temperature:
-17.8 to 65.6 °C

IN STOCK: 42

Can Ship immediately

MOQ for out of Stock Qty: 13

Factory Lead-Time 14 Weeks

Price (USD)

Qty
Unit Price
1
$38.10
5
$38.01
10
$37.90
13
$37.81
25
$29.50
38
$27.16
50 +
$26.63
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
