XTD4C3A by cutler-hammer / eaton

XTD4C3A

Cutler-Hammer / Eaton

Switch Toggle ON None ON DPDT Round Lever Solder Lug 20A 277VAC 28VDC 1118.55VA Panel Mount with Threads Bag ...

Datasheet
RoHS Compliant
Packaging
Accessories
Discontinued
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The CUTLER HAMMER/EATON XTD4C3A is a high-quality toggle switch designed for a variety of applications. This switch features a DPDT (Double Pole Double Throw) configuration, allowing for versatile operation. The toggle lever has a round shape and is easy to handle. It is solder lug terminations, providing secure connections. With a maximum operating current of 20A at 277VAC and 28VDC, this switch offers reliable power control. The XTD4C3A also has a maximum VA (volt-ampere) rating of 1118.55, ensuring efficient performance. Designed for panel mounting with threads and conveniently packaged in a bag, this switch is easy to install and store.

Search Keywords: XTD4C3A

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Cutler-Hammer / Eaton
Part No:
XTD4C3A
RoHS:
Yes
HTS:
8536509065
COO:
CN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Pole Throw Configuration:
2P2T (DPDT)
Switch Configuration:
On None On
Contact Rating @ Voltage:
1118.55 A
Actuator Style:
Round Lever
Mounting:
Panel Mount with Threads
Thread Size:
15/32-32
Body Orientation:
Straight
Terminal Type:
Solder
Operating Temperature:
0 to 65 °C
Life Cycle:
Discontinued
  This product is discontinued, but still in stock

IN STOCK: 320

Ships today, if you order in

Minimum Order: 5

Price (CAD)

Qty
Unit Price
5
$8.361
25
$7.978
50
$7.825
100
$7.671
250
$7.457
500
$7.289
1,000 +
$7.136
