03DRCG5

The 03DRCG5 is a general-purpose, two-stage power line filter designed for high-performance suppression of common mode and differential mode noise. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Discontinued
Certificate of Compliance

DESCRIPTION

The 03DRCG5 is a high-performance, two-stage power line filter designed to suppress unwanted noise on AC power lines. It operates with a rated voltage of 115/250VAC at 50/60Hz and is designed for a 3A current rating. This filter provides excellent attenuation in a 50-ohm system, with a minimum common mode insertion loss of 65 dB at 1 MHz and a minimum differential mode insertion loss of 65 dB from 1 to 5 MHz. With a maximum leakage current of 0.25mA at 115VAC, it is suitable for applications requiring robust noise suppression for both line-to-line and line-to-ground interference to ensure clean power for sensitive electronic equipment.

Search Keywords: 03DRCG5

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Delta Thermal / EMI / Solenoids
Part No:
03DRCG5
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8548000000
COO:
TH
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
60
Mounting:
Flange Mount
Maximum Voltage Rating:
250 VAC
Maximum Current Rating:
3 A
Operating Frequency:
50,60 Hz
Operating Temperature:
N/A
Life Cycle:
Discontinued
  This product is discontinued, but still in stock

IN STOCK: 120

Ships today, if you order in

Manufacturer Stock: 120   can ship 11/13/26

Minimum Order Quantity: 5

Price (USD)

Qty
Unit Price
5
$17.43
25
$15.85
60
$15.15
120
$11.95
300
$11.92
540
$11.89
1,020 +
$11.86
