AFB0412SHB by delta thermal / emi / solenoids
Image is representational - see manufacturer specifications
Delta Thermal / EMI / Solenoids Authorized Distributor

AFB0412SHB

Axial Square-40mm L x 40mm H x 15 mm W 12VDC 2 Wire Leads ...

View Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The AFB0412SHB is a DC Fan Axial Voltage - Rated 12VDC Size / Dimension Square - 40mm L x 40mm H Width 15.00mm Air Flow 14.8 CFM (0.414m³/min) Static Pressure 0.601 in H2O (149.7 Pa) Bearing Type Ball Fan Type Tubeaxial Noise 41.5 dB(A) Power (Watts) 3.00W RPM 11000 RPM Termination 2 Wire Leads Operating Temperature 14 ~ 158°F (-10 ~ 70°C) Approvals CE, CSA, UL, VDE Weight 0.055 lb (24.95g) Current Rating (Amps) 0.250A Voltage Range 7 ~ 13.8VDC Material - Frame Plastic Material - Blade Plastic Lifetime @ Temp. 70000 Hrs @ 40°C

Search Keywords: AFB0412SHB

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Delta Thermal / EMI / Solenoids
Part No:
AFB0412SHB
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8414596590
COO:
TH
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
448
Category:
DC Fan
Dimension:
40 x 40 x 15 mm
Voltage Rating:
12 V
Power Rating:
3 W
Maximum Airflow:
14.8 CFM
Noise Level:
41.5 dB
Special Features:
None
Termination:
Lead Wires
Housing Material:
Plastic
Operating Temperature:
N/A

IN STOCK: 0

On Order: 896   can ship 4/23/27

Minimum Order Quantity: 5

Factory Lead-Time 45 Weeks

Price (USD)

Qty
Unit Price
5
$25.40
25
$17.38
50
$12.29
100
$11.44
448
$11.08
896
$11.05
1,344 +
$11.02
Supplier's Standard Package
Log in for special pricing

Tools/3D Models

Product Guides
